100W 250-700mA one4all Dimmable lp PRE DALI Constant Current LED Driver

Tridonic,LCA 100W 250/275/300/325/350/375/400/450/500/550/600/650/700mA one4all lp PRE,LED Converter Linear DALI, Made In Austria,5yrs Warranty

28000661

Qty: Order Item Add to Wishlist

Dimmable built-in constant current LED Driver, ready2mains Programmer, I-SELECT 2 plugs or DALI for current adjustment, High Efficency, Wide dimming range, Nominal life-time up to 100000 hr, Terminal blocks: 0° push terminals, one4all interface.
Tridonic is a world-leading supplier of lighting technology, supporting its customers with intelligent hardware and software and offering the highest level of quality, reliability and energy savings. As a global driver of innovation in the field of lighting-based network technology, Tridonic develops scalable, future-oriented solutions that enable new business models for lighting manufacturers, building managers, systems integrators, planners and many other types of customers. Tridonic has been Show More...
To Follow
Quick Spec
Brief Description100W 250-700mA one4all Dimmable lp PRE DALI Constant Current LED Driver
Colour FinishWhite
Item Nett Weight (kg)0.292kg
Length (mm)360mm
Width (mm)30mm
Height (mm)21mm
Energy ClassA++ to A
Protection ClassClass 2 - Double Insulated
DimmableYes - Suitable Dimmer Required
Dimmer IncludedNo
IP RatingIP20
Average Life (hrs)100000hrs
Warranty (yrs)5yrs
Features
Adjustable output current , Constant light output function, Power-up fading at AC, Service monitor to log certain events ,Over temperature, Short-circuit, Overload, Noload, Input voltage range, reduced surge amplification. Application-oriented operating window for maximum compatibility.
Full Specifications
Collection GroupLCA
BarcodeTo Follow
Brief Description100W 250-700mA one4all Dimmable lp PRE DALI Constant Current LED Driver
Colour FinishWhite
Item Nett Weight (kg)0.292kg
Length (mm)360mm
Width (mm)30mm
Height (mm)21mm
Energy ClassA++ to A
Max Energy ClassA++
Min Energy ClassA
Lumen Maintenance (hrs)50000hrs / LM80 (±5%)
Type of DriverConstant Current
Dimming Range (%)1-100%
Power Factor (?)>0.97 (±5%)
Constant Current Output (mA)250-700mA
Min/Max. Voltage Output (V)80-220V
Load Range (W)55-100W
Typical Current Ripple (%)±2%
Maximum Output Distance (m)2m
Ta (°C)-25° to +50°C
Tc (°C)80°C
Casing MaterialMetal Body
Connection TerminalTerminal Block
Dimming ProtocolDALI DT 6, DSI, switchDIM, corridor FUNCTION, ready2mains
Efficiency0.83
Protection ClassClass 2 - Double Insulated
Total Power Consumption (W)100W (±5%)
Input Voltage (V)220-240V~50/60Hz
Input Current (A)0.500 A
DimmableYes - Suitable Dimmer Required
Dimmer IncludedNo
IP RatingIP20
Average Life (hrs)100000hrs
Warranty (yrs)5yrs
UKCA/CEYes
RohsYes
ENECYes
SELVYes
Number of Cartons1
Carton Length (cm)36.0cm
Carton Width (cm)3.0cm
Carton Height (cm)2.1cm
Carton CBM0.0002
Carton Nett Weight (kg)0.292kg (±5%)
Carton Gross Weight (kg)0.292kg (±5%)
Additional DetailsTridonic, LCA 100W 250-700mA one4all lp PRE
UK Commodity Code85044090
Country of OriginAustria
